Plastic ball valves are suitable for intercepting the conveying process with corrosive media, depending on the temperature of different materials -14℃ ~ 100℃, -40℃ ~ 140℃. All parts are assembled by RPP or PVDF injection parts, and the plastic ball valve has excellent corrosion resistance. The sealing ring USES F4. Excellent corrosion resistance and long service life. Flexible rotation, easy to use.
Produet Parameters
Nominal diameter
DN25-DN100
Connection type
flange
Applicable medium
PVC compatible with food industry chemical solvents
Body material
UPVC(-10℃~70℃)、CPVC(-40℃~95℃)、
RPP(-14℃~100℃)、PVDF(-40℃~140℃)
Plug material
UPVC(-10℃~70℃)、CPVC(-40℃~95℃)、
RPP(-14℃~100℃)、PVDF(-40℃~140℃)
Sealing material
PTFE,EPDM,NBR
Size
Model
Φ
A
L
H
mm
DN 25
TOP-105
32
21.5
12.1
207
DN32
TOP-105
40
26.5
137
211
DN 40
TOP-105
50
31
161
242
DN 50
TOP-110
63
37.5
195
289
DN65
TOP-110
75
43.5
226
315
DN 80
TOP-116
90
51
289
344
DN 100
TOP-120
110
61
342
376
