The protection level of the shell refers to the protection level and waterproof level of the shell of the electric actuator, which is indicated by the letter IP followed by two digits. The first digit represents the protection level from 1 to 6, and the second digit represents the waterproof level from 1 to 8. The larger the number, the higher the degree of protection.
Product Parameters
Model/Parameter
Output Torque
Power Supply Voltage
Motor Power (W)
Current (A)
Running Time
Connection Dimension
Square Hole
Round Hole
TOP-105
50
DC24V
13
1.28
30s(5-10s speed up,35-60s slow down)
11×11
φ13
AC24V
10
1.5
14×14
AC110V
10
0.24
AC220V
10
0.16
AC380V
6
0.07
TOP-110
100
DC24V
25
2.03
17×17
φ16.1
AC24V
25
2.12
AC110V
25
0.57
AC220V
25
0.35
AC380V
15
0.1
TOP-116
160
DC24V
40
3
17×17
φ19.1
AC24V
40
0.63
AC110V
40
0.45
AC220V
40
0.35
AC380V
30
0.19
TOP-120
200
DC24V
35
3.57
22×22
φ22.3
AC24V
40
3.65
AC110V
40
0.45
AC220V
40
0.37
AC380V
30
0.16
TOP-140
400
DC24V
70
5.13
30s(10s speed up,35-60s slow down)
22×22
φ22.3
AC24V
90
6.8
AC110V
90
1.12
AC220V
90
0.57
AC380V
40
0.29
45s(15s speed up,60s slow down)
TOP-160
600
DC24V
70
6.04
22×22
φ28.7
AC24V
90
6.8
AC110V
90
1.18
AC220V
90
0.6
AC380V
40
0.29
TOP-1100
1000
DC24V
100
8.5
50s(30s speed up,60s slow down)
27×27
φ32
AC24V
100
9
AC110V
120
1.93
AC220V
120
0.94
AC380V
90
0.44
31×31
TOP-1200
2000
AC380V
100
9
27×27
φ32
(N.m)
(optional)
(optional)
(optional)
(optional)
