Electric actuators are mainly used in power plants or nuclear power plants because a high-pressure water system requires a smooth, stable, and slow process. The main advantages of electric actuators are high stability and constant thrust that can be applied by the user. The anti-deviation ability of the electric actuator is very good, and the thrust or torque output is basically constant.
Product Parameters
| Model |
Standard Running Time/Torque |
Optional Running Time/Torque |
Rotation Angle Range |
Voltage Type |
| TOP-105 | 25s/50Nm |
4s/20Nm 10s/30Nm |
0- 90°adjust able |
DC 24V AC 24V AC 110V AC 220V AC 380V |
| TOP-110 | 25S/100Nm | 15s/50Nm | ||
| TOP-116 | 25s/160Nm | 15s/80Nm | ||
| TOP-120 | 25s/200Nm | 15s/100Nm | ||
| TOP-140 | 25s/400Nm | 15s/200Nm | ||
| TOP-160 | 25s/600Nm | 15s/300Nn | ||
| TOP-1100 | 50s/1000Nm | 25s/500N | ||
| TOP-1200 | 50s/2000Nm | 25s/1000Nm | ||
|
Insulation Resistance |
100MΩ/500VDC | |||
|
Withstand Voltage Class |
1500VAC 1Minute | |||
| Protection Class | IP65(optional IP67/IP68) | |||
|
Installation Location |
360°install at any angle | |||
|
Electrical Interface |
2-G 1/2 metal connector,corresponding metal cable connector shall be added according to the selected cable during use |
|||
| Ambient Temperature | -20℃-60℃ | |||
| Function Optional |
Over torque protection,Dehumidification heater, Passive contact switch,Operating hand wheel |
|||
