The valve body casting of the electric wire ball valve adopts advanced technology, which matches the TOP electric actuator. The structure is reasonable, the shape is beautiful, the valve seat adopts a spring seal structure, the starting is easy, the valve stem adopts a bottom-loaded structure with an inverted seal, and the valve cavity. When the temperature rises abnormally, the valve stem will not be impacted.
Product Parameters
Model
Standard Running Time/Torque
Optional Running Time/Torque
Rotation Angle Range
Voltage Type
TOP-105
25s/50Nm
4s/20Nm
0-90°adjustable
DC 24V
TOP-110
25S/100Nm
15s/50Nm
TOP-116
25s/160Nm
15s/80Nm
TOP-120
25s/200Nm
15s/100Nm
TOP-140
25s/400Nm
15s/200Nm
TOP-160
25s/600Nm
15s/300Nm
TOP-1100
50s/1000Nm
25s/500Nm
TOP-1200
50s/2000Nm
25s/1000Nm
Insulation Resistance
100MΩ/500VDC
Withstand Voltage Class
1500VAC 1Minute
Protection Class
IP65(optional IP67/IP68）
Installation Location
360° install at any angle
Electrical Interface
2-G 1/2 metal connector, corresponding metal cable connector shall be added according to the selected cable during use
Ambient Temperature
-20℃-60℃
Function Optional
Over torque protection, Dehumidification heater, Passive contact switch, Operating hand wheel
10s/30Nm
AC 24V
AC 110V
AC 220V
AC 380V
Nominal Diameter DN(mm)
DN15~DN250
Nominal Pressure
PN1.6/2.5/6.4MPa
Connection
Threaded connection
Buttwelding Connection
Part Name
boby,bonnet
WCB
CF8(304)
CF8(316)
WCB
CF8(304)
CF8(316)
ball,stem
2Cr13
304
316
2Cr13
304
316
Seal ring,filer
PTFE,PPL
Trial
condition
Medium
Water,steam,oil
Nitric acid and
other corrosive
medium
Nitric acid and
other corrosive
medium
Water,steam,oil
Nitric acid and
other corrosive
medium
Nitric acid and other
corrosive medium
Temperature
-29℃-180℃(PTFE),-29℃~300℃(PPL)
Size
Model
H
L
mm
in
DN20
3/4"
TOP-105
184
85
DN25
1"
TOP-105
193
90
DN32
11/4"
TOP-105
198
112
DN40
11/2"
TOP-110
206
120
DN50
2"
TOP-110
234
145
DN65
21/2"
TOP-116
256
170
DN80
3"
TOP-120
304
200
